Carbon / Stainless Steel / Aluminium Embedded Fin Tube Machine
  • name
  • name

Carbon / Stainless Steel / Aluminium Embedded Fin Tube Machine

MOQ: N/A
Price: N/A
Standard Packaging: Solid fumigated wooden box loaded into 20 feet Container.
Delivery Period: Ex-work within 2 months on receipt of deposits.
Payment Method: T/T, L/C
Supply Capacity: Ex-work within 2 months for one set machine.
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
RELIANCE
Certification
CE,ISO...
Model Number
Reliance-1518
Name:
Embedded Fin Tubes Fining Machine
Tube Material:
Carbon Steel,Stainless Steel, Alloy Steel,copper Etc...
Fin Material:
Aluminum, Copper,Steel
Fin Type:
Embedded Fins/ G Fins
Tube OD:
15.88mm(Min.)
Tube Length:
No Limit
Fin Height:
16mm(Max.)
Fin Pitch:
2mm(Min)
Fin Thickness:
0.28mm~0.55mm
Voltage:
415V / 50HZ (as Per Client's Requirement)
Package:
Plywood Box (export Packing)
Training:
Supplier's Site OPERATION Training
Highlight:

tube finning machine

,

finned tube machine

Product Description

G-Fin machine, tubes outer diameter 3/4" and 1", carbon and stainless steel, aluminium fins



Quick Details

Name

Embedded Fin Tube Machine

 Brand/Mode No   Reliance/ Mode No:1518
Tube Material

Seamless steel tubes(CS,SS,AS)

Welded steel tubes(CS,SS)

Copper/Brass/Brone

Fins

Material

  Alu.1060-O,  Alu. 1060-H14

  Alu 1100-O, Alu. 1050

  Copper



General description of G-Type finning machine.

1. Embedded Machine Mode No: Reliance-1518

2. Embedded Machine Power Output: 380V/50HZ (Chinese Standard).

3. The motors of export embedded finning machine are supplied upon clients’ requests.



One complete set of Embedded Finning Machine consisting  following:

1. Finning head

2. PLC controlled power box

3. Without Finning input racks and output racks (We will offer design drawings before delivery)

5. Technical know-how(Operation Manual in English)



Dimensions Data are in Inches and specification upon your requests.

Tube OD

Fin Height

Fin Thickness

Fins per Pitch(Density)

5/8

3/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

3/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/2

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

Please email us for more information.



Service After Sales

1. Technical support

2. Operation training at your site or in Reliance's Plant or both

3. Information on maximun production criteria

4. Reference charts

5. Specifications for tube and fin strips.



Carbon / Stainless Steel / Aluminium Embedded Fin Tube Machine 0





Carbon / Stainless Steel / Aluminium Embedded Fin Tube Machine 1Carbon / Stainless Steel / Aluminium Embedded Fin Tube Machine 2



Tags:

finned tube machine,

tube finning machine
