ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube
  • name
  • name

ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube

MOQ: N/A
Price: N/A
Standard Packaging: Steel frame case sealed by plywoods with each tube end capped
Delivery Period: Ex-work within 4 weeks after order.
Payment Method: T/T, L/C
Supply Capacity: Daily capacity up to 5,000 Meters
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Reliance
Certification
CE,ISO...
Model Number
L TYPE
Compamy Type M:
Manufacturer, Importer & Exporter
Fin Tube Type:
L Type Fin Tube,Tension Wound L Type Fin Tube
Origin:
China
Nearest Port:
Shanghai Port, China
Highlight:

finned tube

,

fintube

Product Description

ASTM B111/ B111M Standard Copper Alloy Seamless Condense L Type finned tube







Quick Detail:



(1) ASTM B111/ B111M : Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock



(2) Manufacturing process:

    The copper strip is folded into an L SHAPE and wound onto the base tube surface under tension.

    The feet of the fins are joined together and cover the finned surface.





(3) Delivery Condition

    Tube ends are square cut, free burrs, internally dried and air blown clean.



(4) Packing

      The desiccants are put into each package for continental transportation as well.



(5) Applications

      An urgent replancement job during the shutdown of power plant.



(6) Other Specifications

All dimensions are in Inches and specification upon your requests.

Tube OD

Fin Height

Fin Thickness

Fins per Pitch

5/8

3/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

3/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/4

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

1 1/2

5/8,1/2

.015/.016/ .020

6, 7, 8, 9, 10, 11, 12

Pease email us for more information.









ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube 0ASTM B111/ B111M Copper Alloy Seamless Condense L/LL/KL Type Fin Tube 1
